Network Protocols and Features

RF

ZigBee 2.4GHz ISM Band IEEE 802.15.4

Transmitting Protocol

ZigBee: HA profile

Network Topology

Star/ Tree/ Mesh

Measurement Acc

Temperature +/-0.5 ºC / Humidity +/-5%

Receiver Sensitivity

-92dBm

Physical Interface

Antenna

Built-in Antenna

Weight

95g / 3.4oz

Dimensions

3.54" x 1.97" x 1.1" (90mm x 50mm x 28mm)

Power Requirements

Power supply

AA (LR-03) batteries x 2

Run Time

1 year based on sending data per 15 min

Power Consumption

TX : 35mA Sleep : 1.3uA

Operating Environment

Operating Temperature

-10°C – 50°C/ 14 – 122ºF

Operating Humidity

0% – 95%

Storage temperature

-20°C – 60°C
